K1000L\K1500L\K2000L\K3000L\K4000L\K5000L\K6300L K Type Glass Lined Reactors

Product Name: K Type Glass Lined Reactors Another Name: Open Type Glass Lined Reactors Subordinate category: Glass Lined Reactor Product Capacity: 1000L \ 1500L \ 2000L \ 3000L \ 4000L \ 5000L \ 6300L Product Standard:ASME \ PED \ RTN Product Use: As the best equipment for hydrolysis,...

Detailed description

Product Name: K Type Glass Lined Reactors

Another Name: Open Type Glass Lined Reactors

Subordinate category: Glass Lined Reactor

Product Capacity: 1000L \ 1500L \ 2000L \ 3000L \ 4000L \ 5000L \ 6300L

Product Standard:ASME \ PED \ RTN

Product Use: As the best equipment for hydrolysis, neutralization, crystallization, mixing, and emulsifying, the K Type glass lined reactor is widely used in the chemical, petroleum, pharmaceutical, pesticide, food, dye, and other industries.



Product Introduction:

Then Open glass lined reactor is containing high silica glass lined glaze spraying on the surface of the steel container, by high temperature burning process reasonable and firm adherence to the surface of the metal into composite material products, the tank cover glass lined reactor can be separated and tank, is arranged between the sealing gasket through the clip after a week fixed.

Easy to use, easy to maintain and maintain. It has the double advantages of glass stability and metal strength. It is an excellent corrosion resistant chemical equipment. It has corrosion resistance, impact resistance, smooth appearance, insulation, heat resistance, wear-resistant and other reliable performance. Glass lined equipment, such as glass lined reactors, are widely used in chemical, petroleum, pharmaceutical, pesticide, food, dye and other industrial processes. They are the most ideal equipment for hydrolysis, neutralization, crystallization, mixing and emulsification.




Product Features:

1. We have the U.S. ASME certification, European PED certification. The K type glass lined reactor is a reactor designed with separable cover and body. The cover is fastened to the body using clamps, with gaskets between them.

2. Generally, this pressure vessel is suitable for the small capacity chemical processing works.

3. Since the cover can be separated from the body, the chemical process equipment comes with a diversity of agitating methods and is excellent for all kinds of users.

4. Made from TJ09 high end enamel, combining proven and sophisticated enameling technology, this open type glass lined reactor provides remarkable resistance to corrosion, impact and severe change of temperature as well as reliable durability.

5. The production process of open type glass lined reactor adopts pipelining technology, and the quality is reliable.

6. The glass lined reactor is made of electric furnace. The porcelain surface is clean and not easy to collapse. The quality of the porcelain is of the first class and it is difficult to break the porcelain.

7. Have thirty-six glass lined equipment production patented technology, a specification of an electric furnace, burning glass equipment is not deformed.

8. On the surface of glass coating equipment derusting paint, the product looks more beautiful, generous, world-class.

9. Tai Chi glass lined equipment sells well in China and is exported to more than 30 countries and regions.

10. We can design and manufacture all kinds of non-standard glass lined reactor equipment according to the user's needs.



Technical Parameters of the K Type Glass Lined Reactors:

Design Drawing of K1000L-K6300L Glass Lined Reactor



Internal VesselJacket
Design Pressure( MPa )0.4/0.6/1.00.6/1.0
Design Temperature( ℃ )-19 ℃ /200 ℃-19 ℃ /200 ℃
SymbolUsage
aManhole
bAgitator Hole
cThermowell
d, f, g, hSpare
eSightglass
jMedium Outlet
k1,k2,k3In/Outlet
n1,n2,n3Spray Nozzle
mVent Hole


Total Capacity (L)1616217226404170514064707580
Calculated Capacity (Notes 1) (L)1244171421803370433454436561
Jacket Capacity (L)2063003874617748731027
Heat Exchange Area (㎡)4.555.767.239.3311.8513.7416.43
Reference Weight (kg)1820228025353555405549405560
Maind11200130013001600160017501750
Dimensiond21300145014501750175019001900

d3(Notes 2)1468162216221964196421522152

d41080118011801440144015801580

d5700700700800800850850

h11200140018301810229024102875

h2494519519594594632632

h3290330330340340340340

h4600650650700700700700

h3450370040504210465048205470

B1315315315315315350350

B2/510510510510510510

Φ30303030303030
Nozzle DNa300×400300×400300×400300×400300×400300×400300×400
b125125125150150150150
c100100100100100125125
d100100100100100125125
e100125125125125125125
f125125125125125150150
g100100100100100125125
h100125125125125150150
j100100100125125125125
Jacketk132404050506565
Nozzle DNk232404050506565

k332404050506565

n1/505065656565

n2/505065656565

n3////656565

mG3/8''G3/8''G3/8''G3/8''G3/8''G3/8''G3/8''
DriveDN80808095959595
h51320132013201360136013601530
Notes 1: Calculated Capacity: Volume under highneck flange.
Notes 2: Support types could be determined by users; Without special request, lugs would be normally applied.
